DELL EMC PowerEdge R550, 16×2.5″, Intel XS 4309Y (2.8G, 8C/16T, 10.4GT/s, 12MB, Turbo, HT (105W)), 16GB RDIMM 3200MT/s, 480GB SSD SATA HP, PERC H755, iDRAC9 Enterprise, Dual RPS 1100W, TPM 2.0 V3, BCM 57412 DP, Sliding Rails, 3Y NBD

Series: PowerEdge

Model: PowerEdge R550

System Type: Server

System Form Factor: Rack-Mountable

Included Accessories: Rails

Supported CPUs: Xeon Scalable Processors

CPU: Intel Xeon Silver 4309Y Processor

Internal Clock Rate: 2.8 GHz (up to 3.6 GHz)

CPU Core Quantity: 8

Threads Quantity: 16

Max. CPU Bus Clock Rate: 10.4 GT/sec

CPU podnožje: Socket 4189

CPU Installed Quantity: 1

CPU Maximum Quantity Supports: 2

CPU Cache Size: 12 MB

Features: Supports 10 nm Processors

Quantity of Mainboards Supported: 1

Vrsta memorije: DDR4 SDRAM

Memory Form Factor: DIMM 288-pin

Memory Speed: 3200MHz(PC4-25600)

Provides Error Checking Method: ECC

Memory Capacity: 16 GB

Maximum Installable System Memory Storage Capacity: 1 TB

Memory Slot Total Quantity: 16

Memory Features: Registered

Plug-in-card: RAID Controller:
PERC H755 8 GB
Supports: Level 0, Level 1, Level 10, Level 5, Level 50, Level 6, Level 60
SAS/SATA (2 x SFF-8654 (SlimSAS))
Remote Management Controller:
iDRAC9 Enterprise

SSD: 480 GB, SATA III-600, Hot-Swap

Maximum Fans Supported Quantity: 5 count

Networking Form Factor: Integrated

LAN: Gigabit Ethernet

Data Link Protocol Supports: Gigabit Ethernet/Fast Ethernet/Ethernet

Network: Plug-in-card: 10 Gbps (Broadcom BCM57412)

Number of 2.5-inch Hot-Swap Drive Bays: 16

USB 2.0: 2 (USB 2.0 (type A))

USB 3.0: 1 (USB 3.0 (Type A))

VGA: 2 (15-pin D-sub)

LAN: 2 (RJ-45)

SFP+: 2

Power Device Type: Power Supply – redundant

Power Device Location: Internal

Input Voltage: AC 100-240 V

Input Frequency: 50/60 Hz

Power Device Installed Quantity: 2; Redundant (1+1)

Power Device Maximum Quantity Supports: 2

Maximum Output Power: 1100 W

External Color: Black

Mounting Capability: Rackmount

Standard Rack Height: 2 U

Included Accessories: Rails

Maximum Operating Ambient Temperature: 35 °C

Minimum Operating Ambient Temperature: 10 °C

Maximum Non-Operating Ambient Temperature: 65 °C

Minimum Non-Operating Ambient Temperature: -40 °C

Maximum Non-Operating Humidity: 95 %

Minimum Non-Operating Humidity: 5 %

Max. Altitude Operating: 3048 m

Max. Altitude Storage: 12000 m

Height (mm): 86.8 mm

Depth (mm): 685.78 mm

Width (mm): 482 mm

Warranty Products Returnable: Yes

Warranty Term (month): 36 month(s)

Warranty validation Criteria: Serial Number

Warranty Term Notes: Next Business Day

Pack Weight Brutto (kg): 25.1 kg

Pack Weight Netto (kg): 21 kg

Pieces in pack: 1

Box Weight Brutto (kg): 25.1 kg

Retail Packaging Net Weight Carton: 2.3 kg

Retail Packaging Net Weight Plastic: 1.8 kg

Packs in Box: 1

Package Type: Box
