Network Device Type: Router
Data Link Protocol Supports (New): Wi-Fi + LAN + 4G
Installed Flash Memory Storage Capacity: 128 MB
External Device Support: SIM-card Slot
Installed RAM: 512 MB
WAN: up to 1 Gbps SFP
up to 1 Gbps RJ-45
Encryption Algorithm: WPA
WPA2
WPA3
LAN: 1 x 10Base-T/100Base-TX/1000Base-T up to 1 Gbps SFP
4 x 10Base-T/100Base-TX/1000Base-T up to 1 Gbps RJ-45
Line Modulation Type: OFDMA
Supported Networking Compliant Standards: IEEE 802.1Q(VLAN)
Protocols (OSI Model): PPPoE
IPv6
IPsec
ICMP
IGMP
TCP(Crypt)
UDP
L2TP
PPTP
SSL
LDAP
Application Layer: DHCP
SNMP
DDNS
UPnP
Firewall Functions and Protocols: NAT Support
URL Filter
DMZ Support
MAC address filtering
Firewall Encryption Algorithm: 128-bit AES
3DES
DES
IKE
192-bit AES
256-bit AES
MD5
SHA
Router Features: Web Interface
Dual Band
MU-MIMO
Beamforming Technology
DHCP Server
Access Control
Antenna: External
Device Location: External
Status LED Indicators: Activity Status
Certifications: CE, FCC, RoHS
Built-in Devices: Reset Button
Included Accessories: Power Adapter
Quick Start Guide
LAN/WAN: 1 (SFP), 4 (RJ-45)
WAN: 1 (RJ-45)
USB 3.0: 1 (USB 3.0 (Type A))
Power Device Location: External
Maximum Power Consumption: 17.3 W
Width (mm): 226 mm
Height (mm): 35 mm
Depth (mm): 131 mm
External Color: Black
Maximum Operating Ambient Temperature: 40 °C
Maximum Operating Humidity: 90 %
Minimum Operating Ambient Temperature: 0 °C
Minimum Operating Humidity: 10 %
Warranty Products Returnable: Yes
Warranty Term (month): 60 month(s)
Warranty validation Criteria: Serial Number
Pack Weight Brutto (kg): 1 kg
Pack Weight Netto (kg): 1 kg
Pieces in pack: 1
Box Weight Brutto (kg): 1 kg
Retail Packaging Net Weight Carton: 1 kg
Retail Packaging Net Weight Plastic: 1 kg
Packs in Box: 1
Package Type: Box
Economic operator in EU / authorized representative: TP-LINK Deutschland GmbH
Postal address: Am Trippelsberg 100, 40589 Dusseldorf, Germany
Electronic address: https://www.tp-link.com/de/
