GIGABYTE B840M DS3H WF6, AM5, 4x DDR5, mATX

Chipset: AMD B840

CPU podrška: AMD Ryzen 7000 Series
AMD Ryzen 8000 Series
AMD Ryzen 9000 Series

CPU podnožje: Socket AM5

CPU Max. količina: 1

Vrsta memorije: DDR5 SDRAM

Format memorije: DIMM 288-pin

Brzina memorije: 4400MHz
4800MHz(PC5-38400)
5200MHz(PC5-41600)

Max. kapacitet memorije: 256 GB

Količina utora: 4

Provjera pogrešaka: Non-ECC

Značajke memorije: Two DDR Channels
Unbuffered
Dual Rank
Single Rank
XMP
AMD EXPO

Integriran: Storage Controller:
PCI Express 4.0 x4 (2 x M.2 (Key M))
Storage Controller:
Supports: Level 0, Level 1, Level 10
SATA III-600 (4)
Wi-Fi Controller:
Realtek RTL8851BE

Integrirani video kontroler: Da

Model: AMD Radeon Graphics

Integrirani audio: Da

Vrsta: Integriran

Audio izlaz: 7.1 Channel Surround

Audio standard: HD audio

Integrirani LAN: Da

Wi-Fi: 2.4 GHz/5 GHz
IEEE 802.11 b/g/a/n/ac/ax

Bluetooth: Bluetooth 5.3

Podržana brzina: 2.5 Gbps

PCI Express 4.0 x16: 1

PCI Express 3.0 x16: 1

HDMI: 1 (HDMI (Type A))

DisplayPort: 2

USB 2.0: 4 (USB Type-A)

USB 3.2 Gen 1: 1 (USB Type-C); 2 (USB Type-A)

Audio izlaz: 3 (3.5-mm minijack)

LAN: 1 (RJ-45)

Wi-Fi Antenna: 2

PS/2: 1 (6-pin)

BIOS vrsta: AMI

BIOS: Gigabyte Q-Flash
WfM 2.0 Support
PnP 1.0a Support
UEFI
SMBIOS 2.7 Support
DMI 2.7 Support
ACPI 5.0 Support
256 Mb Flash ROM

Nadzor: CPU Temperature
CPU Voltage
System Temperature
System Voltage

Power Connectors Type: 24+8 pin

Mainboard Features: Fan Speed Control
RGB Fusion

Softver: Norton Internet Security (OEM version)

Podržani operativni sustavi: Microsoft Windows 10 64-bit
Microsoft Windows 11 64-bit

Ugrađeni uređaji: Q-FLASH PLUS Button

Format: Micro ATX

Visina (mm): 244 mm

Širina (mm): 244 mm

Jamstvo u Hrvatskoj: Da

Jamstveni rok (mjeseci): 36 mjeseci(a)

Validacija jamstva: Serijski broj

Dužina (mm): 270 mm

Širina (mm): 268 mm

Visina (mm): 68 mm

Bruto težina (kg): 1.3 kg

Neto težina (kg): 1.17 kg

Količina u pakiranju: 1

Bruto težina kutije (kg): 12.53 kg

Težina kartona: 0.05 kg

Težina plastike: 0.03 kg

Količina u kutiji: 10

Vrsta pakiranja: Maloprodajno

EAN kod: 4719331874667
